- Display
Panel Size: Wide Screen 32” (81.28cm) 16:9
Color Saturation : 98% DCI-P3, 100% Adobe RGB, 100% sRGB and 84% Rec.2020
Panel Type : IPS
True Resolution : 3840×2160
Display Viewing Area(HxV) : 708.48 x 398.52 mm
Display Surface : Non-glare
Pixel Pitch : 0.1845 mm
Brightness : 400 cd/? (Typical)/600 cd/? (Peak)
Contrast Ratio : 1000 :1 (Typical)/1000000 :1 (HDR)
Viewing Angle (CR?10) : 178°(H)/178°(V)
Response Time : 5ms (Gray to Gray)
Display Colors : 1073.7M (10bit)
Flicker free : Yes
LCD ZBD Warranty : Yes
Look-up Table :14-bit
DICOM Calibration : Yes
HDR (High Dynamic Range) Support : Yes (HDR-10 )
- Video Feature
ProArt Preset : 9 Modes(Adobe RGB Mode/DCI-P3/DICOM/HDR_PQ Rec2020/sRGB Mode/Rec. 709 Mode/Standard Mode/User Mode 1/User Mode 2)
Color Temperature Selection : 4 Modes
Color Accuracy : ?E< 2
Gamma adjustment : Yes (Support Gamma 1.8/2.0/2.2/2.4/2.6 )
Color Adjustment : 6-axis adjustment(R,G,B,C,M,Y)
QuickFit (modes) : Yes (Alignment Grid/Paper/Ruler/Customization Modes)
Picture-in-Picture : Yes
Picture-by-Picture : Yes (support up to 4 UHD windows)
Low Blue Light : Yes
HDCP support : Yes
- Audio Features
Stereo Speakers : 3W x 2 Stereo RMS
- I/O Ports
Signal Input : HDMI(v2.0) x3, DisplayPort 1.2, USB Type-C
Earphone jack : 3.5mm Mini-Jack
USB upstream : USB3.0 Type-C x1
USB downstream : USB3.0 Type-A x5
- Signal Frequency
Digital Signal Frequency : 30 ~135 KHz (H) /24 ~76 Hz(V)
- Power Consumption
Power On: <56.84W*
Power Saving: <0.5W
Power Off: 0W
Voltage: 100-240V, 50/60Hz
- Mechanical Design
Chassis Colors : Black
Tilt : +20°~-5°
Swivel : +45°~-45°
Pivot : 0°~+90°
Height Adjustment : 0~130 mm
VESA Wall Mounting : 100x100mm
Quick Release Stand Design : Yes
- Security
Kensington lock
- Dimensions
Phys. Dimension with Stand (WxHxD) : 735 x 615 x 240 mm
Phys. Dimension without Stand (WxHxD) : 734.4 x 431 x 66.85 mm
Box Dimension (WxHxD) : 847 x 552 x 350 mm
- Weight
Net Weight (Esti.) : 12.32 kg,
Without Stand: 8.7 Kg,
Gross Weight (Esti.) : 16.7 kg
- Accessories
Power cord
DisplayPort cable (Optional)
USB-C cable (Optional)
USB-C to A cable
Quick start guide
HDMI cable (Optional)
Warranty Card
Color pre-calibration report
- Compliance and Standards
BSMI, CB, CCC, CE, C-Tick, CU, ErP, FCC, ISO-9241-307, J-MOSS, Mac Compliance, PSE, RoHS, TUV-GS, UL/cUL, VCCI, WEEE, WHQL (Windows 8, Windows 7), TUV Flicker-free , KC , eStandby, TUV Low Blue Light
- Note
* measuring a screen brightness of 200 nits without audio/ USB/ Card reader connection
All specifications are subject to change without notice. Please check with your supplier for exact offers. Products may not be available in all markets.
