WI-FI Radio Specifications
- Dual radio for simultaneous dual-band operation
- 5 GHz 802.11ax 2×2 MIMO for up to 1.2 Gbps wireless data rate, with Multi User MIMO support (Wi-Fi 6)
- 2.4 GHz 802.11ax 2×2 MIMO for up to 574 Mbps wireless data rate (Wi-Fi 6)
- Maximum (aggregated, conducted total) transmit power (limited by local regulatory requirements):
- 5GHz band: +21dBm (+18dBm per chain, 3dB MIMO gain)
- 2.4Ghz band: +21dBm (+18dBm per chain, 3dB MIMO gain)
|
|
|
|
Power
- Power over Ethernet (POE): 802.3af (class 3)
- Max power consumption (worst-case): 10.1W (PoE), 8.8W (DC)
- DC power (12V)
- Note: Power sources are sold separately unless you purchase the bundle SKU which comes with power options.
|
|
|
|
Additional interfaces
- Uplink Gigabit Ethernet port, with PoE-in support (802.3af)
- DC power connector (12V)
- Bluetooth Low Energy (BLE) radio
- LED status indicators (2)
- Reset/LED control button
- Kensington security slot
|
|
|
|
Antennas
- Down-tilt omni-directional antennas for 2×2 MIMO with peak antenna gain of 4.3dBi in 2.4GHz and 5.6dBi in 5GHz (of the effective, combined pattern for both antennas in each band).
|
|
|
|
Mounting
- The access point ships with a white mount clip that can attach to both wall and ceiling.
- You can also purchase a mount (R6P90A) for aesthetic design and looks of the APs, to blend seamless into your environment.
|
