Huawei eKit Wireless Access Point DualBand,WiFi 6,1.8 Gbps,Smart Antenna,1GE uplink,POE w/o AC,beltéri
Original price was: 33 730 Ft.29 330 FtCurrent price is: 29 330 Ft.
Huawei eKit Wireless Access Point DualBand,USB,BLE,WiFi 6,3Gbps,Smart Antenna,1GE uplink,1GE downlink,POE w/o AC,beltér
55 230 Ft
Frekvencia: 2.4 GHz és 5 GHz
Gyártó: Huawei eKit
Kültéri kivitel: Beltéri
Sebesség: up to 2.975 Gbps
Szabvány: 802.11b, 802.11g, 802.11n, 802.11ac, 802.11ax
Kültéri kivitel: Nincs
Garancia: 3 év
Leírás
| Integrated fixed device | Y |
| First supported version | V200R021C01 |
| Installation Type | Desk,Wall,Ceiling,Junction Box |
| Dimensions without packaging (H x W x D) [mm(in.)] | 160 mm x 86 mm x 38 mm (6.30 in. x 3.39 in. x 1.50 in.) |
| Dimensions with packaging (H x W x D) [mm(in.)] | 75 mm x 205 mm x 115 mm (2.95 in. x 8.07 in. x 4.53 in.) |
| Weight without packaging [kg(lb)] | 0.320 kg (0.705 lb) |
| Weight with packaging [kg(lb)] | 0.542 kg (1.195 lb) |
| CPU | 2-core, 1.0 GHz |
| Memory | DDR3L: 512 MB |
| Storage | NAND Flash 256 MB |
| Console port | BLE console |
| Maximum power consumption [W] | 12 |
| Maximum heat dissipation [BTU/hour] | 41 |
| Power supply mode | DC adapter,PoE |
| Rated input voltage [V] | 12 V |
| Input voltage range [V] | 12±10% PoE: 802.3at/af |
| Service port surge protection [kV] | PoE port: Differential mode (48 V-RTN): 0.5 kV (1.2/50 us, 42 ohms), criterion B Common mode (8 wires to ground): 6 kV (1.2/50 us, 42 ohms), criterion B |
| Maximum number of physical ports on the entire device | GE (RJ45) x 2, 10M/100M/1000M auto-sensing |
| Long-term operating temperature [°C(°F)] | 0°C to 40°C (32°F to 104°F) (If the altitude is in the range of 1800 m to 5000 m, the temperature decreases by 1°C or 1.8°F every time the altitude increases by 300 m.) |
| Storage temperature [°C(°F)] | –40°C to +70°C (–40°F to +158°F) |
| Long-term operating relative humidity [RH] | 5% RH to 95% RH |
| Long-term operating altitude [m(ft.)] | –60 m to +5000 m (–196.85 ft to +16404.20 ft) |
| Atmospheric pressure [kPa] | 53kPa – 106kPa ETSI 300 019-2-3 |
| Ground | floating ground |
| USB | USB 2.0 (supporting 5 W power supply) |
| BLE | BLE5.0 |
| Radio number | 2 |
| Operating frequency band | 2.4GHz,5GHz |
| MIMO spatial streams | Radio 0 (2.4 GHz): 2×2 Radio 1 (5 GHz): 2×2 |
| Wi-Fi standard | 2.4G: 802.11b/g/n/ax 5G: 802.11a/n/ac/ac Wave 2/ax |
| Radio interface | Built-in smart antennas |
| Antenna gain | 2.4G: 2 dBi/chain (peak value) 1 dBi (combined gain) 5G: 3 dBi/chain (peak value) 1 dBi (combined gain) BLE: 4 dBi |
| Maximum transmit power | 2.4G: 20 dBm/chain 23 dBm (combined power) 5G: 20 dBm/chain 23 dBm (combined power) BLE: < 10 dBm |
| 3G/LTE filte (ACC) | Not supported |
| MTBF [year] | 69.7 |
| MTTR [hour] | 0.5 |
| Frequency stability [ppm] | +/-20 |
| 802.3at power supply description | No function is limited. |
| 802.3af power supply description | The USB function is unavailable. |
| DC power supply description | No function is limited. |
További információk
| Tömeg | 0,55 kg |
|---|---|
| Készlet |
Elérhető |
| Brand |
Huawei eKit |
