MERCUSYS Wireless Router Dual Band AX3000 1xWAN(2500Mbps) + 3xLAN(1000Mbps), MR85X
17 760 Ft
Származási ország: Kína
Garancia: 3 év
- Wi-Fi Class
-
AX3000
- Wi-Fi (2.4 GHz)
-
574Mbps
- Wi-Fi ( 5 GHz)
-
2402Mbps
- Wireless Standards
-
802.11ax/ac/a/b/g/n
- Max Channel Width
-
160MHz
- Reception Sensitivity
-
5G:
11a 6Mbps: -95dBm
11a 54Mbps:-76.5dBm
11n HT20 MCS7:-76dBm
11n HT40 MCS7:-73dBm
11ac VHT20 MCS8:-71.5dBm
11ac VHT40 MCS9:-67dBm
11ac VHT80 MCS9:-63.5dBm
11ax HE20 MCS11:-64.5dBm
11ax HE40 MCS11:-63dBm
11ax HE80 MCS11:-58.5dBm
11ax HE160 MCS11:-56dBm2.4G:
11g 6Mbps : -97dBm
11g 54Mbps: -79dBm
11n HT20 MCS7:-78dBm
11n HT40 MCS7:-75dBm
11ax HE20 MCS11:-66.5dBm
11ax HE40 MCS11:-65.5dBm
- Max Wi-Fi Modulation
-
1024 QAM
- Wireless Security
-
WPA/WPA2/WPA3
- Wireless Functions
-
Guest Network
Smart Connect
Wireless Schedule
WPS
AP Isolation
Airtime Fairness
- Wireless
- Dimensions
-
209 × 171.7 × 42.4 mm
(8.2 × 6.8 × 1.7 in) - Interfaces
-
1× 2.5G WAN
3× GE LAN - Antenna
-
2× 5G External Antennas(5dBi)
1× 2.4G & 5G External Antenna(2.4G: 3dBi, 5G:5dBi)
1× 2.4G External Antenna(5dBi) - Button
-
1× WPS Button
1× Reset Button - Installation
-
Desktop
Wall-mount - LED
-
1× SYS
- Retail Package Dimension
-
359 × 274 × 60mm
- Units per Carton
-
10
- Carton Dimension
-
560 × 370 × 310mm
- IPTV
-
IGMP Proxy
IGMP Snooping
Bridge
Tag VLAN - Power
-
Input:100~240V, 50/60Hz
Output: 12V/1.5A
- Hardware
- Operation Mode
-
Router/AP mode
- WAN Mode
-
Dynamic IP
Static IP
PPPoE
PPTP
L2TP - NAT Forwarding
-
Port Forwarding
Port Triggering
DMZ
UPnP - Protocols
-
IPv4
IPv6 - Guest Network
-
2.4G Guest Network
5G Guest Network - Parental Controls
-
Profile Settings
Time Control
Pause the Internet
Website Filtering - DHCP
-
Address Reservation
DHCP Client List
Server - DDNS
-
MERCUSYS
NO-IP
DynDNS - VPN Server
-
OpenVPN
PPTP
L2TP/IPSec
WireGuard - VPN Client
-
OpenVPN
PPTP
L2TP/IPSec
WireGuard - Easymesh
-
Easymesh Compatible
- QoS
-
Time Settings
Priority Control - Security
-
SPI Firewall
Access Control
IP & MAC Binding - Kill Switch
-
Support
- ISP Feature
-
CWMP
ISP Preset(Agile Config)
Superadmin - System
-
Firmware Upgrade
Backup and Restore
Administration
System Log
Time & Language Settings
Reboot - Diagnostics
-
Ping
Traceroute - LED Management
-
LED Control
Night Mode - Device Management
-
MERCUSYS APP
Webpage - Cloud
-
MERCUSYS ID
- Language
-
Bulgarian
Czech
Danish
German
English
Spanish
Finnish
French
Hungarian
Italian
Japanese
Korean
Dutch
Norwegian
Polish
Portuguese
Portuguese – Brazil
Romanian
Russian
Slovak
Swedish
Turkish
Ukrainian
Vietnamese
Chinese – Taiwan - Advanced Features
-
OFDMA
MU-MIMO
BSS Color
Beamforming
- Software
- Network Services Enabled by Default
- Web Server Manage and configure device through web (HTTP/HTTPS) • Port: 80/443 Protocol: TCP
DNS DNS • Port: 53 Protocol: TCP & UDP
DHCP Server IP address assignment (DHCP) • Port: 67 Protocol: UDP
App management Manage and configure device through app • Port: 20001 Protocol: TCP • Port: 30001 Protocol: TCP • Port: 20002 Protocol: UDP
- Network Services Enabled by Default
-
Web Server
Manage and configure device through web (HTTP/HTTPS)
• Port: 80/443; Protocol: TCP
DHCP Server
IP address assignment (DHCP)
• Port: 67; Protocol: UDP
DNS
DNS
• Port: 53; Protocol: TCP & UDP
App management
Manage and configure device through app
• Port: 20001; Protocol: TCP
• Port: 20002; Protocol: UDP
- Package Contents
-
• AX3000 Wi-Fi 6 Router MR85X
• Power Adapter
• Quick Installation Guide
• RJ45 Ethernet Cable - Environment
-
• Operating Temperature: 0°C~40°C (32°F~104°F)
• Operating Humidity: 10%~90% Non-Condensing
• Storage Humidity: 5%~90% Non-Condensing
- Others
| Tömeg | 0,88 kg |
|---|---|
| Készlet |
Elérhető |
| Brand |
TP-Link |
