MSI Alaplap S1700 B760M GAMING PLUS WIFI Intel B760, mATX

56 330 Ft

Modellszám	B760M GAMING PLUS WIFI
Videochip gyártó	Intel
Foglalat	LGA1700
Memória foglalat	DDR5
Készlet	Elérhető
Brand	Msi
Súly	1.26 kg
Info code	CH
Garancia	36 hónap

Cikkszám: B760M GAMING PLUS WIFI Kategória: Alaplap Márka: Msi

Leírás

Leírás

CHIPSET	INTEL B760M
CPU SUPPORT	Supports 12th/13th Gen Intel® Core™ Processors, Pentium® Gold and Celeron® Processors LGA 1700
MEMORY	4x DDR5, Maximum Memory Capacity 192GB Memory Support DDR5 6800+(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz Max. overclocking frequency: • 1DPC 1R Max speed up to 6800+ MHz • 1DPC 2R Max speed up to 6400+ MHz • 2DPC 1R Max speed up to 6000+ MHz • 2DPC 2R Max speed up to 5600+ MHz Supports Intel^® XMP 3.0 OC Supports Dual-Controller Dual-Channel mode Supports non-ECC, un-buffered memory
ONBOARD GRAPHICS	1x HDMI™ Support HDMI™ 2.1 with HDR, maximum resolution of 4K 60Hz* 1x DisplayPort Support DP 1.4, maximum resolution of 4K 60Hz* *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed.
EXPANSION SLOT	5x PCI-E x16 slot PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset) PCI_E4 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E5 Gen PCIe 3.0 supports up to x1 (From Chipset)
STORAGE	2x M.2 M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280/2260/2242 devices M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices 4x SATA 6G * SATA8 will be unavailable when installing M.2 SATA SSD in the M2_2 slot.
RAID	Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
USB	4x USB 2.0 (Rear) 4x USB 2.0 (Front) 2x USB 3.2 Gen1 Type A (Front) 1x USB 3.2 Gen1 Type C (Front) 2x USB 3.2 Gen2 Type A (Rear) 1x USB 3.2 Gen2 Type C (Rear)
LAN	Realtek^® RTL8125BG 2.5G LAN

Technikai adatok:

Audio: 7.1 HD
Chipset gyártó: Intel
Foglalat típusa: S1700
Form Factor: ATX
Grafikus foglalat: 2 x PCI-Ex16x
Gyártó: MSI COMPUTER
Kivitel: Dobozos
LAN1: 100/1000/2500 Mb/s
Max memória: 192,0000000
Memória foglalatok száma: 4,0000000
Memória órajel: 5600,0000000
Memória típus: DDR5
PCI foglalatok száma: 0,0000000
PCI-E foglalatok száma: 1,0000000
Raid: Igen
SATA III: 4,0000000
USB 2.0: 4,0000000
Wireless: Van
USB 3.1: 4,0000000
D-Sub: Nincs
HDMI: Van
Display Port: Van
Thunderbolt: Nincs
Soros port: Nincs
Párhuzamos port: Nincs
DVI: Nincs
Quad Channel: Nincs
M.2 foglalat: Van
