TP-LINK Wireless Access Point Tri-Band BE9300 Wifi 7 Beltéri/Kültéri, EAP772-OUTDOOR

Name: TP-LINK Wireless Access Point Tri-Band BE9300 Wifi 7 Beltéri/Kültéri, EAP772-OUTDOOR
Brand: TP-Link
SKU: EAP772-OUTDOOR
Availability: InStock

124 630 Ft

Bridge funkció: Van
Frekvencia: 2.4 GHz és 5 GHz és 6 GHz
Gyártó: TP-LINK
Szabvány: 802.11b, 802.11g, 802.11n, 802.11ac, 802.11ax, 802.11be
Wifi sebesség: 5300 Mbit/s
WAN sebesség: 10/100/1000/2500 Mbit/s
LAN sebesség: 10/100/1000/2500 Mbit/s
POE adapter: Van
Kültéri kivitel: Van
Garancia: 5 év

Add to compare

Cikkszám: EAP772-OUTDOOR Kategória: Access Point Brand: TP-Link

Leírás
További információk

Leírás

HARDWARE FEATURES
Interface	1× 2.5G Ethernet (RJ-45) Port (Support 802.3at PoE)
Button	Reset
Power Supply	• 802.3at PoE
Max. Power Consumption	• EU: 21.5W (for PoE) • US: 23W (for PoE)
Dimensions ( W x D x H )	9.1× 8.2 × 2.8 in (230 × 207.5 × 69.7 mm)
Antenna	• 2.4 GHz: 2× 4 dBi • 5 GHz: 2× 6 dBi • 6 GHz: 2× 6 dBi
GNSS	L1 (1575.42 MHz) receiver, supporting GPS, Galileo, GLONASS, and BeiDou signals Receive sensitivity: -164dBm (tracking) GPS antennas: Integrated 3dBi omnidirectional antennas
Bluetooth	BLE 5.2
Weatherproof Enclosure	IP68
Mounting	Pole/Wall Mounting (Kits included)

WIRELESS FEATURES
Coverage	300m² (3,200ft²) Recommended Omnidirectional Coverage
Concurrent Clients	250+⁶
Wireless Standards	IEEE 802.11be/ax/ac/n/g/b/a
Frequency	2.4 GHz, 5 GHz, 6 GHz
Signal Rate	• 802.11be: 8.6 Mbps to 5765 Mbps (MCS0-MCS13, NSS = 1 to 2 HE20/40/80/160/240/320) • 802.11ax: 8.6 Mbps to 2402 Mbps (MCS0-MCS11, NSS = 1 to 2 HE20/40/80/160) • 802.11ac: 6.5 Mbps to 2166.7 Mbps (MCS0-MCS9, NSS = 1 to 2 VHT20/40/80/160) • 802.11n: 6.5 Mbps to 300 Mbps (MCS0-MCS15, HT20/40) • 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps • 802.11b: 1, 2, 5.5, 11 Mbps • 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Wireless Functions	• 4k-QAM • Multiple SSlDs • OFDMA • Multiple SSIDs (Up to 16 SSIDs, 8 for each band) • Enable/Disable Wireless Radio • Automatic Channel Assignment • Transmit Power Control (Adjust Transmit Power on dBm) • QoS (WMM) • MU-MIMO • MLO • 320MHz • Omada Mesh³ • Seamless Roaming(802.11k/v/r)³ • Band Steering • Load Balance • Airtime Fairness • Beamforming • Rate Limit • Reboot Schedule • Wireless Schedule • Wireless Statistics based on SSID/AP/Client • Static IP/Dynamic lP
Wireless Security	• Captive Portal Authentication³ • Access Control • Wireless Mac Address Filtering • Wireless Isolation Between Clients • SSID to VLAN Mapping • Rogue AP Detection • 802.1X Support • WEP, WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
Transmission Power	• CE: <20 dBm (2.4 GHz, EIRP), <28 dBm(5 GHz, band 3, EIRP) • FCC: <25 dBm (2.4 GHz), <25 dBm(5 GHz), <25 dBm(6 GHz)

Management Features
Omada App	Yes
Centralized Management	Yes, through • Omada Cloud-Based Controller • Omada Hardware Controller (OC300) • Omada Hardware Controller (OC200) • Omada Software Controller
Cloud Access	Yes, through • Omada Cloud-Based Controller • Omada Hardware Controller (OC300) • Omada Hardware Controller (OC200) • Omada Software Controller
Email Alerts	Yes
Management MAC Access Control	Yes
SNMP	v1, v2c
System Logging Local/Remote Syslog	Yes
SSH	Yes
Web-based Management	Yes
L3 Management	Yes
Multi-site Management	Yes
Management VLAN	Yes
Zero-Touch Provisioning	Yes. Requiring the use of Omada Cloud-Based Controller

OTHERS
Certification	CE, FCC, RoHS
Package Content	• Access Point EAP772-Outdoor • Power Cord • Mounting Kits • Installation Guide
System Requirements	Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux
Environment	• Operating Temperature: -30–70 ? (-22–158 ?) • Storage Temperature: -40–70 ? (-40–158 ?) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing
