UBiQUiTi POE Adapter 1000Mbps, 60W, 48VDC @ 1,25A – U-POE++

Dimensions

106 x 63 x 34 mm (4.2 x 2.5 x 1.3")

Weight

210 g (7.4 oz)

Power Cable

Included

Output Voltage

48V DC at 1.25A

Rated Voltage

100–240V AC at 50/60Hz

LAN Activity Indicator

—

Gigabit LAN Port

?

Remote Reset Capability

—

Reset Button

—

4-pair Powering

Pins 1, 2, 4, 5 (+) and 3, 6, 7, 8 (-)

AC Connector

IEC-320 C6

Clamping Protection

11V Data, 60V power

Data In / PoE

RJ45 Shielded Socket

Input Current

1.3A @ 120V AC

Inrush Current

<100A peak @ 120V AC <200A peak @ 230V AC

Efficiency

85+%

Switching Frequency

65 kHz

Output Ripple

1% Max.

Line Regulation

≤ 1%

Load Regulation

≤ 3%

Max. PoE+ Wattage per Port by PSE

60W

Max. Surge Discharge

1500A (8/20 μs) power

Peak Pulse Current

36A (10/1000 μs) data

Power Method

Universal AC input, 100–240V AC, 50/60 Hz

Power Supply

AC/DC

Response Time

<1 ns

Shunt Capacitance

<5 pF data

Supported Voltage Range

100–240V AC

Surge Protection

Difference and common mode

Ambient Storage Temperature

-30 to 70°C (-22 to 158° F)

Ambient Operating Temperature

0 to 40° C (32 to 104° F)

Ambient Operating Humidity

10 to 95% noncondensing

NDAA Compliant

?

Certifications

CE, FCC, IC, UKCA, KC, CCC, RoHS
